Dual Channel Power Amplifiers, Power Amplifiers, Sound System, XDA-3002
XDA-3002
Availability:
10 in stock
- Dual Channel Class D Power Amplifier.
- 1200 + 1200 Watts rated output.
- 80Hz/120Hz Low Pass Filter.
- Built-in Limiter ON/OFF circuit.
- Toroidal Transformer power supply.
- Two selectable input sensitivities.
- Built-in Amplifier Protection system: DC offset, HF, Short circuit, Thermal, Overload, Over voltage & Clip Monitoring.
₹33,667.00
10 in stock
Compare-
Dual Channel Power Amplifiers, Power Amplifiers, Sound System, XDA-3002
XDA-3002
- Dual Channel Class D Power Amplifier.
- 1200 + 1200 Watts rated output.
- 80Hz/120Hz Low Pass Filter.
- Built-in Limiter ON/OFF circuit.
- Toroidal Transformer power supply.
- Two selectable input sensitivities.
- Built-in Amplifier Protection system: DC offset, HF, Short circuit, Thermal, Overload, Over voltage & Clip Monitoring.
SKU: SEB-DC-PA-MA-05 -
DPA-570®M, Medium Wattage PA Mixer Amplifiers, Sound System
DPA-570®M
MEDIUM WATTAGE PA MIXER AMPLIFIER
- 3 Mic & 1 Aux Input.
- Built-in MP3 player with USB reader and remote control.
- Bluetooth facility.
- Line Output for connecting to a Booster Amplifier.
- Cut and Boost type Bass & Treble controls.
- Instant transfer to DC Power (Car Battery) if AC power fails.
SKU: SEB-MW-PA-MA-08 -
Medium Wattage PA Mixer Amplifiers, Sound System, SSB-120®
SSB-120®
- 5 Mic & 2 Aux Inputs.
- Line Ouput for connecting to a Booster Amplifier and Preamplifier Output for recording the programme.
- Cut type Bass & Treble controls.
- Instant transfer to DC power (Car Battery) if AC power fails.
SKU: SEB-MW-PA-MA-01
₹57,856.00 for 3 item(s)
| Continuous Rated Power Stereo/Mono | 8Ω : 700W + 700W RMS, 4Ω : 1200W + 1200W RMS |
| THD + N | < 0.1% |
| Frequency Response (-1dB) | 20-20,000Hz |
| Low Pass Filter | 80/120Hz @ 24dB per octave |
| Power Bandwidth (0.5% THD) | 20-20,000Hz |
| Input Sensitivity | 0dBu (775mV) & 4dBu (1.23V) (Selectable) |
| Input Impedance | 10k Unbalanced, 20k Balanced |
| Signal To Noise Ratio | > 100dB |
| Channel Separation | > 65dB at 1kHz |
| Damping Factor (8W) | >1000 |
| Slew Rate | 20V/µs |
| Protections | Temperature, DC, RFI, Short Circuit, Overload, Overvoltage, Built-in Limiter (ON/OFF) AC: Circuit Protector 16A; ± DC: Fuse 2×16A (T 16A L) |
| Input Connectors | 2×XLR, Stereo Phone Jack 6.3mm |
| Output Connectors | Speakon 4-Way and heavy duty Binding Post for each channel |
| Cooling | 2 × Variable Speed DC Fan with Temperature Sensing |
| Front Panel Controls | 2×41 Step Level Attenuators |
| Indicators | Power ON/FAULT, Signal, Clip, Temperature, Protect (Ch. A & B) |
| Power Consumption (Rated) | 2800VA @ 220-240V ~ 50/60Hz |
| Dimensions | W482 × H104 × D438mm |
| Weight | 18.80kg |
XDA-3002
1200+1200 WATTS
Dual Channel Class D Power Amplifier
- Dual Channel Class D Power Amplifier.
- 1200 + 1200 Watts rated output.
- 80Hz/120Hz Low Pass Filter.
- Built-in Limiter ON/OFF circuit.
- Toroidal Transformer power supply.
- Two selectable input sensitivities.
- Built-in Amplifier Protection system: DC offset, HF, Short circuit, Thermal, Overload, Over voltage & Clip Monitoring.
- Compact 2U Size.
- BIS approved.
